MS866-22 Push-to-Close Compression Latch with Stainless Steel (or Carbon Steel) Body and Zinc Alloy Locking Mechanism
The MS866-22 Push-to-Close Compression Latch is engineered for secure and reliable closure of doors, panels, and enclosures, offering both ease of operation and enhanced security. Constructed with stainless steel (or carbon steel) for the panel and handle, zinc alloy for the lock tongue, and carbon steel for the cover plate, this latch provides robust protection against contaminants. The push-to-close function ensures fast and easy sealing, while the locking mechanism provides extra security, compatible with the default K53 key.
Material:
- Panel & Handle: Stainless Steel or Carbon Steel
- Locking Mechanism: Zinc Alloy (Lock Tongue)
- Cover Plate: Carbon Steel
Surface Finish and Color/Appearance:
- Stainless Steel Handle & Panel: Mirror Polished Finish
- Carbon Steel Handle & Panel: Nano Spray Coating
- Lock Tongue & Cover Plate: White Zinc Plating
Products Categories
Get A Free Quote
Key Features
- Push-to-Close Function: Enables quick and secure closure with a simple push, ensuring an airtight seal.
- Compression Mechanism: Prevents the ingress of moisture, dust, and contaminants.
- Locking Mechanism: Provides added security with the option for a lock head and compatibility with the K53 key.
- Durable Construction: Stainless steel or carbon steel body, zinc alloy lock tongue, and carbon steel cover plate ensure durability and longevity.
- Corrosion Resistance: Mirror-polished stainless steel or nano-coated carbon steel, with zinc-plated components for superior corrosion protection.
- Easy Installation: Pre-drilled holes for quick and easy installation.
Specifications
- Handle Bearing Pull Force: ≤1000N
- Lock Tongue Load Capacity: ≤500N
- Dimensions:
- Length: 60mm
- Width: 28mm
- Depth: 26mm
- Mounting Hole Diameter: Ø7mm
- Key: Default K53 Key
Applications
- Electrical cabinets
- Industrial enclosures
- Server racks
- Outdoor equipment housings
- Commercial and military equipment
Keywords
MS866-22, MS866-22S, Push-to-Close Latch, Compression Latch, Locking Latch, Stainless Steel Latch, Zinc Alloy Compression Latch, K53 Key Compatible, Industrial Latch, Waterproof Latch, Panel Latch
