MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat
MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat
MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat
MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat
MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat
MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat

MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat

The MS828 rod control lock is designed for secure, multi-point control in industrial enclosures and cabinets. Its 180° rotation and quick-release mechanism allow for efficient locking and unlocking, making it ideal for applications requiring multiple locking points. Equipped with a user-friendly push button and automatic handle ejection, it ensures convenient access while maintaining robust security.

Material:

Zinc alloy base, handle, push button; Q235 steel backplate, carbon steel rod, linkage components.

Surface Finish:

Matte black powder coating on the handle and base, optional satin nickel plating.

Color/Appearance:

Available in matte black and satin nickel finishes.

Products Categories
Get A Free Quote
Contact Form Demo (#3)

Key Features

  • 180° rotational locking mechanism for multi-point control
  • Push-button activation with automatic handle ejection
  • Secure key locking for enhanced security (default K100 key)
  • Multi-point locking with adjustable linkage options for varied applications

Specifications





MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat MS828 Rod Control Lock, Multi-Point Control, Key Locking, 1-5mm Panel, Zinc Alloy, Black Powder Coat

  • Handle Bearing Tension:  ≤340N
  • Handle Bearing Torque:  ≤28N.m
  • Compatible Panel Thickness:  1-5mm

Applications

  • Industrial cabinets and enclosures
  • Control panels requiring secure, multi-point locking
  • Utility access doors with customizable locking points

Keywords

Rod control lock, multi-point lock, MS828, industrial enclosure lock, multi-point locking system, adjustable linkage, key lock, zinc alloy rod lock, alternative, compression latch, MS828-1F, MS828-8-L-F, MS828-9, MS828-A-F, MS828-8-2D.
