MS767 Series Budget Lock with Hooked Tongue and Right/Left-Hand Options
The MS767 Series Budget Lock is a versatile and cost-effective locking solution designed for light-duty applications. Manufactured from zinc-plated pressed steel, this series offers reliable performance and corrosion resistance. With a simple quarter-turn operation, it’s ideal for enclosures, cabinets, and light industrial equipment.
This series includes two models with distinctive dimensions and configurations:
- MS767-1: Features a hooked tongue, suitable for right-hand applications.
- MS767-2: Designed with an extended locking tongue for left-hand configurations.
Material:
- Lock Body: Zinc-plated mild steel.
- Tongue: Stainless steel.
-
Surface Finish and Color:
- Zinc-plated finish with clear passivation for enhanced corrosion resistance.
Products Categories
Get A Free Quote
Key Features
- Compact Design: Low-profile structure for space-constrained installations.
- Versatile Options: Available in right-hand (MS767-1) and left-hand (MS767-2) configurations.
- Corrosion Resistance: Zinc-plated steel ensures long-term durability.
- Simple Operation: 90° rotation for quick locking and unlocking.
Technical Specifications
MS767-1 (Right-Hand Configuration):
- Length: 100mm
- Width: 42mm
- Cutout Dimension: Ø12mm
- Tongue Type: Hooked
MS767-2 (Left-Hand Configuration):
- Length: 126mm
- Width: 42mm
- Cutout Dimension: Ø15mm
- Tongue Type: Extended
Applications
- Furniture panels and locks.
- Light-duty industrial equipment.
- Enclosures for residential or commercial use.
- Vending machines and storage lockers.
Keywords
MS767, MS767-1, MS767-2, budget lock, hooked tongue lock, quarter-turn latch, zinc-plated lock, right-hand lock, left-hand lock, industrial budget lock, light-duty lock.
