MS750 Keyed and Non-Keyed Push-to-Close Latch for Industrial Applications
BAOTAI’s MS750 Push-to-Close Latch offers both keyed and non-keyed options, providing secure and convenient closure solutions for industrial cabinets and enclosures.
- Dual Configuration: Available with both keyed and non-keyed options to suit various security requirements.
- High Durability: Made of PA66+30%GF, ensuring robustness in industrial environments.
- Water and Dust Protection: Rated IP40 for essential protection against environmental factors.
- Strong Load Capacity: Capable of withstanding a maximum working load of 530N.
- Versatile Installation: Can be installed with the pull tab parallel or perpendicular to the latching cam.
MS750 Keyed and Non-Keyed Push-to-Close Latch Description
The MS750 Push-to-Close Latch by BAOTAI is designed for industrial and commercial use, offering both keyed and non-keyed configurations to meet varying security needs. Constructed from durable PA66+30%GF material, this latch ensures reliable performance in demanding environments. The latch is rated IP40 for protection against dust and water, and it supports a maximum working load of 530N. Installation is flexible, with options for pull tab orientation either parallel or perpendicular to the latching cam, making it adaptable to various industrial setups.
MS750 Push-to-Close Latch Technical Sheet
- Material: PA66+30%GF
- Color: Black
- Head Style: CH751 Key Locking
- Surface Finish: Raised
- Access Restriction: Key Locking, available in keyed and non-keyed configurations
- Installation Dimensions: M25x22
- Grip Range: Min: 22.30 mm, Max: 23.10 mm
- Panel Thickness Compatibility: Min: 0.00 mm, Max: 10.30 mm
- Compliance: UL FTTA2 / FTTA8 Class 1, UL94-HB
- Style: Pull Tab in Line with Latching Cam, configurable for parallel or perpendicular orientation
MS750 Latch Specifications&Benefits
MS750 Latch Specifications
The MS750 Push-to-Close Latch is designed for applications where secure, quick, and convenient access is required. Available in both keyed and non-keyed options, this latch is ideal for industrial cabinets, enclosures, and other applications that demand high durability and reliable performance.
MS750 Latch Benefits
The MS750 Latch provides essential protection against environmental factors such as dust and water, thanks to its IP40 rating. It is engineered to handle a maximum load of 530N, ensuring long-lasting reliability in demanding environments. The availability of both keyed and non-keyed options allows for flexibility in meeting various security needs.
Get a Free Quote for MS750 Latch
Contact BAOTAI for the MS750 Push-to-Close Latch, offering both keyed and non-keyed options for secure industrial applications.
