MS726-1 Compression Lever Latch, Push Button, Key Locking & Non-Locking Options, Zinc Alloy, Chrome-Plated, Adjustable for Varied Door Heights
- The MS726-1 compression lever latch is engineered with a push-button feature for fast and secure access, ideal for industrial and utility applications. This latch offers versatility with both key locking and non-locking options, catering to varied security needs. Constructed from high-strength zinc alloy with a corrosion-resistant chrome-plated finish, the MS726-1 is designed for durability in demanding environments. An adjustable cam allows the latch to accommodate doors of different heights, making it adaptable for diverse installations.
Material:
- Zinc alloy base, lock core, zinc alloy or plastic button, carbon steel rod
Surface Finish:
- Chrome-plated with optional black powder coating
Color/Appearance:
- Chrome with optional red plastic button
Products Categories
Get A Free Quote
Key Features
- Push-button operation for quick and secure access
- Available in key-locking and non-locking configurations for customizable security
- Adjustable cam for installation on doors of various heights
- Robust zinc alloy construction with a chrome-plated, corrosion-resistant finish
Specifications
- IP Rating: IP54, ensuring resistance to dust and water
- Dimensions:
- Overall Height: 72.5mm
- Width: 27mm
- Mounting Hole Size: 23.5mm x 62mm
- Rotation Angle: 45°
- Options Available:
- Key-locking and non-locking
- Zinc alloy button or red plastic button
Applications
- Industrial cabinets
- Utility enclosures
- Control panels requiring quick-access, secure locking solutions
Keywords
- Compression lever latch, push-button latch, MS726-1, zinc alloy latch, key locking, non-locking latch, adjustable height latch, IP54 latch, chrome-plated latch, Southco 62 series alternative, lift & turn latch compatibility
