MS705-Q Zinc Alloy 90-Degree Square Handle Lock with Versatile Applications
The MS705-Q square handle lock is an innovative and durable locking solution, ideal for secure access to panels and enclosures. Featuring a 90-degree rotational design, this lock ensures reliable locking or unlocking functionality. Its zinc alloy construction and polished black finish provide enhanced durability and a sleek aesthetic, making it suitable for industrial and commercial applications.
Materials and Finish
- Handle and Base: Zinc alloy for durability and corrosion resistance.
- Lock Core: Carbon steel (model: S1B32N04002) for structural strength and wear resistance.
- Surface Finish: Matte black coating (peacock green handle option available).
Surface Finish and Appearance
- Black matte finish for a modern look and corrosion protection.
Products Categories
Get A Free Quote
Key Features
- 90-degree rotation mechanism for simple and effective locking or unlocking.
- Compatible with K15-1 lock cores for enhanced versatility.
- Ergonomic square handle design for comfortable operation.
- Corrosion-resistant zinc alloy body for long-lasting performance.
Technical Specifications
- Maximum Static Load: 210N
- Maximum Input Torque: 15Nm
- Recommended Screw Torque: 20Nm
- Dimensions:
- Cutout size: 20.1mm square, Ø22.5mm circular
- Handle dimensions: 42mm x 30mm
- Grip height (GH): 19mm
Applications
- Industrial and electrical panels
- Enclosures and cabinets
- Machinery access panels
Keywords
MS705-Q, MS705-K01, MS705-K02, square handle lock, zinc alloy lock, 90-degree lock, industrial panel lock
