DKS Heavy-Duty Zinc Alloy Draw Latch with Key Lock, Compatible with V7-20-101/111 Series
The DKS heavy-duty draw latch offers a robust and secure fastening solution for industrial and commercial applications. Built with premium zinc alloy and stainless steel components, it ensures durability, high load capacity, and tamper resistance. Featuring an optional key lock, this latch is ideal for securing enclosures, cabinets, and toolboxes.
Material:
- Base, Cover, Keeper: Zinc Alloy
- Fixed Frame: Stainless Steel
-
Surface Finish and Color/Appearance:
- Available in powder-coated black or polished chrome finishes for corrosion resistance and modern aesthetics.
Products Categories
Get A Free Quote
Key Features
- High Load Capacity: Rated for up to 700N static load, suitable for heavy-duty applications.
- Locking and Non-Locking Options: Optional locking mechanism with K080 keys for added security.
- Durable Construction: Tamper-resistant, riveted design using robust zinc alloy and stainless steel.
- Customizable Finish: Offers powder-coated black or polished chrome finishes to suit various environments.
- Ease of Installation: Designed for quick and straightforward mounting with M3 screws.
Specifications
- Maximum Static Load: 700N
- Optional Key: K080 (2 keys included for locking versions)
- Installation: Requires four M3 flat head screws for the latch and two M3 screws for the keeper.
Applications
- Industrial and electrical enclosures
- Automotive and marine storage compartments
- Toolboxes and storage units
- General-purpose closures requiring high load resistance
Keywords
- V7-20-101-10
- V7-20-101-50
- V7-20-111-10
- V7-20-111-50
- Zinc alloy latch
- Industrial locking latch
- Heavy-duty enclosure latch
