CL249 Heavy-Duty Steel Hinge – 180° Opening for Industrial Left/Right Door Applications
The CL249 series hinge is designed to handle high load capacities with precision and durability, making it suitable for industrial and commercial door applications. Constructed from carbon steel (with chrome plating) or stainless steel (with a brushed finish), this hinge offers outstanding strength and corrosion resistance. Supporting a 180° opening angle, the CL249 provides seamless and reliable operation for both left-opening and right-opening doors. With a maximum radial load of 1200N and axial load of 1300N, this hinge is built to endure heavy-duty use while maintaining a smooth performance.
Material and Surface Finish
- Material: Carbon steel with bright chrome plating or stainless steel with a brushed finish.
- Surface Finish Options:
- Carbon Steel: Bright chrome plating for enhanced corrosion resistance.
- Stainless Steel: Brushed finish for a modern, professional appearance.
Products Categories
Get A Free Quote
Key Features
- 180° Opening Angle: Designed for wide, unrestricted access to doors and panels.
- High Load Capacity: Radial load of 1200N and axial load of 1300N for heavy-duty applications.
- Left/Right Door Compatibility: Available for both left-opening and right-opening door configurations.
- Durable and Corrosion-Resistant: Suitable for industrial and outdoor environments.
Specifications
- Mounting Hole Dimensions: 8 holes, Ø5.1 mm countersunk.
- Hinge Length: 108 mm (total width), 65 mm (height).
- Pin Dimensions: Ø16 mm
- Opening Angle: 180°
- Axial Load Capacity: 1300N
- Radial Load Capacity: 1200N
Applications
- Industrial equipment enclosures
- Heavy-duty warehouse doors
- Commercial and industrial access panels
Keywords
CL249 hinge, heavy-duty steel hinge, 180-degree hinge, industrial door hinge, chrome-plated hinge, brushed stainless hinge
