CL213-3 Concealed Hinge, Zinc Alloy, 180-Degree Opening Angle, High Load Capacity
The CL213-3 concealed hinge is engineered for applications that demand both strength and versatility. Constructed with a zinc alloy body and PA pivot, this hinge allows for a 180-degree opening, ensuring wide access for various industrial enclosures and equipment panels. Its robust design provides reliable performance, making it ideal for heavy-duty use.
Material:
Zinc Alloy Body, PA Pivot, Carbon Steel Pin
Surface Finish:
Matte Black (Spray Coating)
Color/Appearance:
Matte Black
Products Categories
Get A Free Quote
Key Features
- 180-degree opening angle for maximum accessibility
- High static load capacity (Axial: 670N, Radial: 255N)
- Concealed design for a seamless appearance and enhanced security
- Zinc alloy construction with PA pivot for strength and durability
Specifications
- Axial Load Capacity: 670N
- Radial Load Capacity: 255N
- Dimensions: Width: 60mm, Height: 43mm, Mounting Hole Diameter: 8mm
Applications
- Industrial enclosures
- Equipment panels
- Control cabinets
Keywords
Concealed hinge, CL213 series, CL213-1, CL213-2, CL213-3, CL213-6, CL213-7, CL213-9, zinc alloy hinge, 180-degree hinge, high-load hinge, Southco alternative
