BT3169 PA6 Latch with Zinc Alloy Gearbox – Sand Texture Finish, for Door Thickness 2mm
The BT3169 is a high-performance latch designed for applications requiring durability and precision. Featuring a PA6 body with a sand texture finish and a zinc alloy gearbox, this latch offers a perfect balance of lightweight design and robust functionality. The 135° rotation of the lock back drives the gearbox components to achieve secure locking or unlocking. Suitable for door thicknesses of 2mm, this latch is ideal for enclosures, cabinets, and access panels in various industries.
- Material: PA6 body, zinc alloy lock back pivot, gearbox, A3 rack.
- Finish: Sand texture for a sleek and durable appearance.
Products Categories
Get A Free Quote
Key Features
- Lightweight Design: PA6 body ensures easy handling and installation.
- 135° Rotation: Lock back rotation drives the gearbox for secure operation.
- Corrosion Resistance: Zinc alloy components enhance durability.
- Aesthetic Appeal: Sand texture finish provides a modern and professional look.
- Precision Design: Lock plate opening size: 8×8mm, ensuring easy installation and secure fit.
Specifications
- Model Number: BT3169
- Material: PA6 body, zinc alloy lock back pivot, gearbox, A3 rack
- Surface Finish: Sand texture
- Door Thickness Compatibility: 2mm
- Lock Plate Opening Size: 8×8mm
- Dimensions:
- Length: 25mm
- Width: 16.1mm
- Height: 14.5mm
- Mounting Hole Specifications:
- Hole spacing: 12.4mm
- Hole diameter: 3mm
- Length: 25mm
Applications
- Industrial enclosures and cabinets.
- Utility boxes and access panels.
- Lightweight security doors and gates.
- Electrical and mechanical equipment requiring robust latches.
